Suitable for light, medium truck type trucks, using engine driven refrigeration units
It is the first choice for transporting refrigerated frozen food, dairy products, vegetables, fruits, milk, shrimp seedlings, vaccines and industrial electronics. Its refrigeration performance is very stable and reliable. SNOWFALL one or more of this series will meet your needs.
SF-310, a transport refrigerating unit driven by engine, is a reliable refrigerating unit for refrigerating preservation vehicles with the dimensions of 7~-16m in the thermal insulation compartment, and also has the option of built-in bottom-hanging condenser
Feature:
1. Optional DC 12V or 24V for you to choose, and backup electric refrigeration system DC220V/DC380V optional installation.
2. The whole transport refrigerating unit is light and compact, the condenser is in front, and the evaporator can be installed as required.
3. This series of models fully covers the refrigerated capacity ranging from 7 m to 45m and accurately matches its refrigerated volume from per square meter.
Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
4. Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
Model | SF - 328 | |||
Applicable Temperature (℃) | 15 ~ -25 | |||
Cooling Capacity | Environmental Temperature | 35°C | ||
0°C | 3200Kcal | |||
-18°C | 1960Kcal | |||
Compressor | Model | QP16 | ||
Displacement(cc/r) | 168cc | |||
Condenser | Type | P.F. | ||
Fan Type | Axial fan | |||
Number of Fan | 2Fans x 1000m3/h | |||
Voltage | DC 12V/DC24V | |||
Evaporator | Type | Inner screw tube and aluminium fin | ||
Fan Type | Axial fan | |||
Number of Fan | 2 Fans x1000m3/h | |||
Voltage | DC 12V/DC24V | |||
Power Consumption | ≤ 30A (DC12V) | |||
Refrigerant | R-134a/R-404a | |||
Defrost Type | Automatically hot air defrost | |||
Structure | Split direct drive unit | |||
Dimensions (mm) /Net weight(kg) | SF-328 Evaporator | L640x W1290x H180 | 30.2 kg | |
SF-328 Condenser | L520x W1080 x H370 | 28.3kg | ||
SF-U328 Condenser | L640x W1290x H180 | 30.2kg | ||
SF-U328 Condenser | L310 x W885 x H375 | 15.6kg | ||
Electric Standby system(optional part) | AC 220V /AC 380V |
